RODE M1, M1-S, M2 & M3 Microphone

RODE M1 Specs

Key Specs

Microphone Type	Handheld
Element Type	Dynamic
Polar Pattern	Cardioid
Frequency Range	75 Hz to 18 kHz
Analog Output	1x XLR 3-Pin
Power Sources	No Power Required

Microphone

Primary Applications	Live Sound, Studio Recording
Microphone Type	Handheld
Intended Sound Sources	Vocals
Sound Field	Mono
Element Type	Dynamic
Polar Pattern	Cardioid
Orientation	End Address
Circuitry	Solid-State
Pad	No
High-Pass Filter	No
Gain Adjustment	No

Performance

Frequency Range	75 Hz to 18 kHz
Sensitivity	-56 dB at 1 kHz

Connectivity

Analog Output

1x XLR 3-Pin

Power

Power Sources

No Power Required

Physical

Color	Black
Mounting Thread Size	5/8"-27 Female (3/8"-16 Female with Included Adapter)
Dimensions	ø: 2.03 x L: 6.73" / ø: 51.5 x L: 171 mm
Weight	12.7 oz / 360 g

Packaging Info

Package Weight	1.55 lb
Box Dimensions (LxWxH)	8.4 x 3.5 x 3.4"

• RODE M1 Handheld Cardioid Dynamic Microphone
• RODE RM1 Stand Mount
• RODE ZP1 Zip Pouch - for Rode S1, NT1-A, NT2-A, NT3, NT1000, NTG1 or Broadcaster microphones
• Limited 1-Year Warranty with Extension to Lifetime Following Registration

The RØDE’s M1-S live dynamic microphone is designed to deliver the best performance with rock-solid build quality and high-power neodymium capsule. When used as a handheld microphone, the M1's ergonomically built all-metal body is engineered for optimal comfort. The microphone's internal design virtually eliminates handling noise, and it feels sturdy, substantial, and precisely balanced without being heavy. It's smooth character and defined clarity give outstanding performance as a live vocal microphone, with a warm response that is incredibly defined for a dynamic microphone. The spill and feedback are minimised via a precisely controlled cardioid polar pattern. The M1-S also has an XLR lock that may be used to secure the microphone to the cord for more security. A flush-mounted lock is included to prevents the microphone from being switched by accident.

• Live dynamic vocal microphone
• High output neodymium capsule
• Cardioid polar pattern
• Lockable on/off switch
• XLR security lock
• Ergonomically designed heavy duty all-metal body
• Low handling noise



Model :M1-S

Weight (kg) :1

Length (cm) :22

Height (cm) :9

Width (cm) :9

The RØDE's M2 is a tough live-performance condenser microphone with a wide frequency response and excellent on-stage performance. The M2 has a tailored-for-stage super-cardioid polar pattern and an internally shock-mounted 1/2" condenser capsule. The addition of an on/off switch adds versatility for artists that prefer greater control over their sound, while a lock prevents the microphone from being accidently switched.

• Live condenser vocal microphone
• Feedback rejecting super-cardioid pick up pattern
• Lockable on/off switch
• Ergonomically designed heavy duty all-metal body
• High level of RF rejection
• Low handling noise

Brand :

Rode

Model :

M2

Weight (kg) :

1

Length (cm) :

28

Height (cm) :

14

Width (cm) :

9



FEATURES

• Acoustic principle: Permanently polarized condenser
• Directional pattern: Cardioid
• Frequency range: 40Hz-20kHz
• Output impedance: 200 ohms
• Signal noise ratio: 73dB SPL (per IEC651)
• Equivalent noise: 21dbA SPL (a - weighted per IEC651)
• Maximum SPL: 142dB (@ 1kHz, 1% THD into 1kohm load)
• Sensitivity: -40dB+/-3dB re 1V/Pa @ 1kHz (6.3mV/Pa @ 94db SPL)
• Dynamic range din iec 651: 121dB (per IEC651)
• Battery life: >200 hours
• Output connection: 3 pin XLR
• Complete with windshield and a stand mount
• Powered by battery or +48V phantom power

SPECIFICATIONS

• Microphone Type:Condenser
• Polar Pattern:Cardioid
• Diaphragm Size:0.5" (12.5mm)
• Frequency Response:40Hz-20kHz
• Max SPL:142dB
• Output Impedance:200 ohms
• Signal to Noise Ratio:73dB
• Self Noise:21dB
• Low Cut Filter:80Hz
• Pads:-10dB, -20dB
• Connector:XLR
• Weight:0.86 lbs.

Dimension Packaging Weight : 1.2 kg

IN THE BOX:
- Rode M3
- Padded Zip Pouch
- RM3 Microphone Clip
- WSM3
- Limited 1-Year Warranty, Extendable to 10 Years upon Registration
